4020U
WARNING: This product can expose you to chemicals including Diisononyl Phthalate (DINP) and Lead, which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Downloads
Specification Details
| Parts per Unit | 5, 50 |
|---|---|
| Features | Copper alloy, tin plated for added conductivity and corrosion resistance, Exceeds SAE standards, J163 and J1811, Made in USA, Permanent, indelible, readable gauge, and polarity stamped on clamp For crimp or solder applications, Precise dimensions to fit battery posts for maximum contact, Quick Connectors are listed by UL® (UL® STD 486A) & CUL , when applied with Quick Cable Quick Crimp tools 4255, 4255M, 4255R & 4255MR (standard and ratchet versions) |
| Product Height | 0.65 in |
| SKU | 4020-005U, 4020-050U, 4020U |
| RoHS Compliant | Yes |
| Production Process | Cast |
| Product Type | Straight Clamp |
| Product Width | 1.00 in |
| Product Length | 2.34 in |
| Color Code | Orange |
| Color | Silver |
| Brand | QUICK |
| Works With | Top Posts |
| Wall Thickness | Heavy Wall |
| UL / CSA | Yes |
| Termination Method | Crimp |
| Termination Material | Copper |
| Subject to Prop 65 | No |
| SAE | J163, J1811 |
| Polarity | Universal |
| Plating Material | Tin |
| Pack Type | Bag |
| Gauge | 2/0 |
| Includes | Fasteners |
| Application | Crimp, Solder |
| Product Weight | 0.13 lb |
| Country of Origin | USA |
