163207

The Non-Insulated Solderless Ring has a serrated barrel for greater wire retention and pullout strength.

WARNING: This product can expose you to chemicals including Diisononyl Phthalate (DINP) and Lead, which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

Downloads

163207 INFO Last Updated: 06/09/2022

Specification Details

Parts per Unit

100, 1000, 25, 50

Features

3 part construction contains: inner lug, additional copper sleeve for added strength, crimpability and seamless outer nylon cover, Designed for heavy-duty applications to resist vibration and moisture, Serrated barrel for greater wire retention/ pullout strength, Tin plated annealed copper for improved corrosion resistance, max conductivity and crimp strength

Product Height

0.20 in

SKU

163207, 163207-025, 163207-050, 163207-100, 163207-1000

RoHS Compliant

Yes

Product Type

Nylon Ring Double Crimp

Product Width

0.54 in

Product Length

1.24 in

Color

Blue

Brand

Not branded

Works With

Primary Wire

UL / CSA

No

Termination Method

Crimp

Termination Material

Copper

Subject to Prop 65

No

Stud/Tab Size

3/8 in

SAE

No

Plating Material

Tin

Pack Type

Bag

Maximum Voltage

600 V

Insulation Material

Nylon

Insulation Color

Blue

Gauge

14, 16

Application

Harsh

Product Weight

0.002 lb

Country of Origin

Taiwan
