5615
WARNING: This product can expose you to chemicals including Diisononyl Phthalate (DINP) and Lead, which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Downloads
Specification Details
| Parts per Unit | 1, 10, 5, 50 |
|---|---|
| Features | 3:1 Shrink Ratio, Class 1 and 2 specifications, Conforms to DOD Mil-DTL-23053/15A, Meets UL – 486D specifications, Premium quality for heavy-duty applications |
| Expanded Diameter | 1 1/8 in |
| SKU | 5615, 5615-001B, 5615-005B, 5615-010B, 5615-050B, 5615-051B |
| RoHS Compliant | Yes |
| Product Length | 1.50 in, 48.00 in, 6.00 in |
| Color | Black |
| Brand | MagnaTube |
| Waterproof | Yes |
| Adhesive | Yes |
| UL / CSA | No |
| Tensile Strength | 11.5 PSI |
| Temperature Range (°F) | -67 to 230°F |
| Temperature Range (°C) | -55 to 110°C |
| Subject to Prop 65 | No |
| Shrink Ratio | 3:1 |
| SAE | No |
| Post Shrink Wall Thickness | 1/8 in |
| Pack Type | Bag |
| Nominal Wall Thickness | 0.118 in |
| Flame Retardant | Yes |
| Body Material | Polyolefin |
| Gauge | 1/0, 2/0, 250 MCM, 3/0, 4/0 |
| Application | Battery Connectors |
| Shrunk Diameter | 3/8 in |
| Country of Origin | China |
