201806
WARNING: This product can expose you to chemicals including Diisononyl Phthalate (DINP) and Lead, which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Specification Details
| Parts per Unit | 100, 25, 250, 50 |
|---|---|
| Features | Copper conductor for maximum conductivity, Excellent low temperature flexibility, Fine stranded, annealed bare copper wire, High resistance to UV light and ozone exposure, Meets UL 62 for SJE, SE, and SEO, More flexible than strandard battery cable, Oil, water, acid resistant (SGT) thermoplastic rubber compound, Water resistant safety insulator/separator for additional protection against corrosion or cut through |
| Application | Battery Cable, Ground, Jumpers, Marine Rating, Starters |
| Gauge | 1/0 |
| Conductor Material | Copper |
| Cable Nominal Outer Diameter | |
| Insulation Material | SGT |
| Insulation Thickness | 0.1 in |
| Pack Type | Roll |
| SAE | J1127, J378C |
| Strand Count | 1064 |
| Strand Gauge | 30 |
| Subject to Prop 65 | No |
| Temperature Range (°C) | -50 to 105°C |
| Temperature Range (°F) | -58 to 221°F |
| UL / CSA | No |
| Voltage | 600 V |
| Works With | Copper Connectors |
| Brand | Not branded |
| Cable Nominal Outer Diameter | 0.61 in |
| Color | Red |
| Product Length | 10.25 in, 12.00 in, 14.00 in |
| Product Width | 10.25 in, 12.00 in, 6.00 in |
| RoHS Compliant | Yes |
| SKU | 201806, 201806-025, 201806-050, 201806-100, 201806-250 |
| Cable Length | 100 ft, 25 ft, 250 ft, 50 ft |
| Product Weight | 10.65 lb, 106.50 lb, 21.30 lb, 42.60 lb |
| Country of Origin | USA |
