200108
WARNING: This product can expose you to chemicals including Diisononyl Phthalate (DINP) and Lead, which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Specification Details
| Parts per Unit | 10, 100, 25, 250, 50, 500 |
|---|---|
| Features | Copper conductor for maximum conductivity, Insulation is flame-retardant, Meets or exceeds SAE J1127, SGT type, PVC insulation resists abrasion, fuel, oil, acid and salt |
| Cable Length | 10 ft, 100 ft, 25 ft, 250 ft, 50 ft, 500 ft |
| SKU | 200108, 200108-010, 200108-025, 200108-050, 200108-100, 200108-250, 200108-500 |
| RoHS Compliant | Yes |
| Product Width | 1.62 in, 10.25 in, 12.00 in, 6.00 in |
| Product Length | 10.25 in, 12.00 in, 14.00 in |
| Color | Black |
| Cable Nominal Outer Diameter | 0.66 in |
| Brand | Not branded |
| Works With | Copper Connectors |
| Voltage | 60 V |
| UL / CSA | No |
| Temperature Range (°F) | -58 to 221°F |
| Temperature Range (°C) | -50 to 105°C |
| Subject to Prop 65 | Yes |
| Strand Gauge | 22 |
| Strand Count | 259 |
| SAE | J1127 |
| Prop 65 Item | DEHP, DINP |
| Pack Type | Roll |
| Insulation Thickness | 0.055 in |
| Insulation Material | PVC |
| Cable Nominal Outer Diameter | |
| Conductor Material | Copper |
| Gauge | 3/0 |
| Application | Automotive, Commercial, Industrial, Truck |
| Product Weight | 15.40 lb, 171.35 lb, 31.04 lb, 328.51 lb, 6.38 lb, 61.62 lb |
| Country of Origin | USA |
