165502
WARNING: This product can expose you to chemicals including Diisononyl Phthalate (DINP) and Lead, which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Specification Details
| Parts per Unit | 100, 25 |
|---|---|
| Features | Heat shrink with meltable adhesive seals the connections, Melting temperature, 138°C (280°F), Operating temperature, -55°C (-67°F) to 110°C (230°F), Provide a high quality, secure, sealed connection, Soldered terminations provide superior strength and conductivity |
| Product Height | 0.36 in |
| SKU | 165502, 165502-025, 165502-100 |
| RoHS Compliant | Yes |
| Product Type | Lead Free Butt Connector |
| Product Width | 0.36 in |
| Product Length | 1.50 in |
| Color | Yellow |
| Brand | Not branded |
| Works With | Primary Wire |
| UL / CSA | Yes |
| Termination Method | Solder |
| Termination Material | Lead Free Solder |
| Subject to Prop 65 | No |
| SAE | No |
| Pack Type | Bag |
| Maximum Voltage | 600 V |
| Insulation Material | Polyolefin |
| Insulation Color | Yellow |
| Gauge | 10, 12 |
| Application | General Purpose |
| Product Weight | 0.01 lb |
| Country of Origin | Taiwan |
