162260

The Nylon Insulated Solderless Male Disconnect is made of tin-plated annealed copper for improved corrosion resistance, maximum conductivity and crimp strength.

WARNING: This product can expose you to chemicals including Diisononyl Phthalate (DINP) and Lead, which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

Specification Details

Parts per Unit

100, 1000, 25, 5, 50

Features

Designed for heavy duty applications and superior performance, Serrated barrel for greater wire retention/pullout strength, Tin plated annealed copper for improved corrosion resistance, maximum conductivity and crimp strength

RoHS Compliant

Yes

Product Width

0.25 in

Product Length

0.96 in

Color

Blue

Brand

Not branded

Works With

General Purpose

UL / CSA

No

Termination Method

Crimp

Termination Material

Copper

Subject to Prop 65

No

Stud/Tab Size

1/4 in

SAE

No

Plating Material

Tin

Pack Type

Bag

Insulation Material

Nylon

Gauge

14, 16

Application

For general purpose applications

SKU

162260, 162260-025, 162260-100, 162260-1000, 162260-2005, 162260-2050

Country of Origin

Taiwan
